Energy EV battery connector 2pin 100A and 4pins 10A pack assembly connector

Energy EV battery connector 2pin 100A and 4pins 10A pack assembly connector

The BMS battery pack Pak high-voltage single core connector has not released the national standard for the high-voltage connector of power battery in China. Most enterprises implement the enterprise standard or refer to the standards of other similar products, or directly borrow the connectors used in other industries. The above reasons pose challenges to the safety and interchangeability of the connector in the process of use. Energy EV battery connector 2pin 100A and 4pins 10A pack assembly connector.

  • description
  • Application
  • Case
  • Download
1.MATERIAL:
   BODY:THERMOPLASTIC,UL94V-0.
   CONTACT:COPPER ALLOY.
2.SPECIFICATIONS:
   2.1 RATED CURRENT:2pin : POWER 100 AMP, 8pin : SIGNAL 5AMP.
   2.2 RATED VOLTAGE:300V DC/AC.
   2.3 OPERATING TEMPERATURE:-20°C~+85°C.
   2.4 RoHS COMPLIANT.
3.ALL MATERIALS SHALL BE CERTIFIED COMPLIANT TO

  THE LATEST RoHS DIRECTIVE.



1.MATERIAL:
   BODY:THERMOPLASTIC,UL94V-0.
   CONTACT:COPPER ALLOY.
2.SPECIFICATIONS:
   2.1 RATED CURRENT:2pin : POWER 100 AMP, 8pin : SIGNAL 5AMP.
   2.2 RATED VOLTAGE:300V DC/AC.
   2.3 OPERATING TEMPERATURE:-20°C~+85°C.
   2.4 RoHS COMPLIANT.
3.ALL MATERIALS SHALL BE CERTIFIED COMPLIANT TO
  THE LATEST RoHS DIRECTIVE.
